| 型 號 | Model | YG-G2 |
| 電 源 | Power | AC220V 50/60 Hz 單相(single-phase) |
| 功 能 | Function | 電線切斷、單端剝皮、雙端剝皮、單端壓著、雙端壓著 Wire cutting, single-end stripping, both-end stripping, single-end pressing, and both-end pressing |
| 產 能 | Productivity | 4800 條 / 小時（ 300mm以?xún)?nèi)） 4800 pieces/hour (within 300mm) |
| 電線規格 | Wire specification | AWG32 -- AWG18 |
| 剝皮長度 | Stripping length | A端:0.5mm--13mm(20mm不含打端、35mm半剝) B端:0.5mm--10mm |
| 加工長度 | Processing length | 30mm--9999mm(指中間留皮部分refer to the middle part with skin) |
| 切斷精度 | Cutting precision | 誤差少于1mm(設定長度x0.002)可修正 The error less than 1mm (set length x 0.002) can be corrected. |
| 空氣壓力 | Air pressure | 5--8kgf(需使用清潔干燥空氣) 5-8kgf (need clean and dry air) |
| 檢測裝置 | Testing equipment | 入線異常、氣壓不足、沖模不良、端子有無、未打端、未剝皮 Abnormal entering, insufficient pressure, unsound punching, no terminal, no ending, and no stripping |
| 壓著能力 | Pressing capacity | 2.0噸 |
| 外觀尺寸 | External dimensions | 700W x 880L x 1500H mm |
| 重量 | Weight | 400kg |
